Db Technologies ES 602 - Column PA system
Kaina 539 €779 €Sutaupykite 240 €ES602 is a portable system composed by one passive top and one 10” subwoofer. The sub hosts a 800 W peak power amp module with auto-range PSU. A powerful DSP manages both the coverage and the functions of the system, making the ES602 a real gem in terms of sound performance and versatility.
-
Technical Data
Speaker Type bi-biamped system, with one full range top and one subwoofer
Acoustical data
Frequency Response [-10dB]44 – 15.000 Hz
Max SPL118 dB
MF - HF 4x 3"
Type MF - HFNeodymium
LF10"
Directivity95x65°
Amplifier
Amp TechnologyDigipro® G3
Amp ClassClass-D
Power Amp Peak800 W
Processor
ControllerDSP 24 Bit/48 kHz
System PresetsFactory presets
LimiterDual Active, Peak, RMS, Thermal
Crossover Frequency LF-HF 210 Hz
Input
Mic/Instrument Channel1x Combo (XLR/Jack) balanced/unbalanced input, 1x RCA stereo input
Link Output1x XLR balanced output
Mechanics
Housing (Subwoofer)15mm Black Painted Plywood
Housing (Tops)Polypropylene PP
Handles2x lateral side (Subwoofer)
Width (Top) 95 mm (3.74 in)
Height (Top)360 mm (13.98 in)
Depth (Top)137 mm (5.39 in)
Width (Subwoofer)300 mm (13.8 in)
Height (Subwoofer)400 mm (15.7 in)
Depth (Subwoofer)430 mm (16.9 in)
Weight (Top)1.9Kg – 4.19lbs.
Weight (Subwoofer)14.2Kg – 31.48lbs.
