Audio Specification

Signal-to-Noise Ratio: > 94dB
Max Output Level: +24dBu
Inputs: (6) combo XLR/TRS
Phantom Power: 48VDC
Maximum Voltage Gain: 60dB

Mic Inputs
Max Input Level: -20dBu
Sensitivity: -40dBu
Impedance: 1.4kΩ

Line Inputs
Max Input Level: +24dBu
Impedance: 10kΩ

Equalizer
High: ± 15dB @ 12kHz
Mid: ± 12dB @ 2.5kHz
Low: ± 15dB @ 80Hz

Environmental
Operating Temperature: 40 - 140°F (5 - 60°C)
Operating Humidity: 25 ~ 85% (non-condensing)

General
Power Requirement: 100 ~ 240VAC 50/60Hz
Power Consumption: < 5W
Dimensions: 19.0 x 7.7 x 1.7” (483 x 195 x 44mm)
Weight: 5.6 lbs. (2.5 kg)
